General features
Actuator:
Complete with actuator with high coding level VN NS-F41
Housing:
Technopolymer housing
Working method:
E working method, locked actuator with energised solenoid
Mode 1: OS safety outputs active with locked protection
Inputs and outputs :
2 safety inputs IS1-IS2,
2 safety outputs OS1-OS2,
1 signalling output O3: actuator inserted,
1 signalling output O4: actuator locked,
2 solenoid activation inputs IE1-IE2,
1 programming / reset input I3,
1 feedback input EDM I5
Auxiliary release with variable orientation:
Without release
Output connection direction:
Cable or connector at bottom
Type of connection:
PVC cable 12x0.14 mm2, length 4m
Protection degree:
IP67 according to EN 60529 and IP69K according to ISO 20653
Button configuration:
No device
